Aerospace & Automotive Inconel 718 Deep Hole Drilling 🕜 Efficiency remained consistent | 📈 Quality - stable & consistent hole diameter | ⚙️ Tool Life - with the pilot drill, the tool can finish drilling 60 through holes in a stable manner Difficulties in Machining HIT Achievements Industry Application Back to list Inconel 718 Deep Hole Drilling - Difficulties in Machining What makes Inconel 718 difficult to machine? The major difficulties in machining Inconel 718 lie in its material properties. Inconel alloys are known for their resistance to oxidation and corrosion. When heated, Inconel forms a thick, stable, passivating oxide layer protecting the surface from further attack. Repeated machining motions (pecking or drilling) on Inconel can cause work hardening and place extra wear and tear on the tools. This makes Inconel difficult to shape and to machine by using traditional methods. ☑️ Inconel 718 Machining Information Inconel 718 Machining Information Material Inconel 718 Dimensions Φ1 (tool spec.) x 20mm [aspect ratio : 20] Methods Deep hole drilling Machine Tool Buffalo MCU-5X Max. Spindle Speed 15,000 rpm (18,000/24,000 rpm) Tool Rotating Speed 10,000~13,000 rpm Spindle Taper BT40 / CAT40 / HSKA63 Tool Holder HSKA63-10 Integrated System CTS (67bar); ATC; CNC Automation Inconel 718 Deep Hole Drilling - HIT Achievements (Figure. ultrasonic machining on Inconel 718 workpiece) HIT's Goal in Machining Inconel 718 To see ultrasonic-assisted machining effects on deep hole drilling Inconel 718 for 60 through holes. Ultrasonic-Assisted Machining Inconel 718 Results HIT completed drilling 60 through holes on Inconel 718. The processing time for each hole took around 4 seconds. The average hole diameter was well-controlled at Φ1.003mm. HIT Ultrasonic Machining Technology Achievements 🕜 Efficiency remained consistent 📈 Quality - stable & consistent hole diameter ⚙️ Tool Life - with the pilot drill, the tool can finish drilling 60 through holes in a stable manner Inconel 718 Deep Hole Drilling - Industry Application Deep hole drilling Inconel 718 has been widely applied in the Aerospace industry and Automotive industry, especially for aircraft components (heat shields, gas turbine blades, engine exhaust piping, etc.) and automotive components (battery pack contactor, turbine wheel, etc.). Products with this kind of feature in Inconel 718 usually take enormous amount of time and cost huge amount of money on the drillling tools. 💡 Inconel 718 aircraft components : Aircraft components have to handle and withstand years of operation under high temperature and high pressure environments. The hear shields, jet engines, and engine exhaust systems in the aerospace industry benefit significantly when Inconel alloys are incorporated into their systems. Machining this kind of material usually comes with great expense in time and money due to its machining characteristics. This is where HIT's Ultrasonic Machining Module comes in handy! We offer a comprehensive solution in machining these difficult-to-cut materials. With the assistance of our Ultrasonic Machining Technology, cutting force is greatly reduced and the coolant can function effectively due to high-speed frequency oscillation. We can assure our clients of fulfilling their needs and even achieving better outcome! 💡 Inconel 718 automotive components : Automotive industry is under more and more pressure to create fuel-efficient and pollution-controlled engines and other components. With the outstanding combination of strong mechanical structure and corrosion resistance, Inconel alloys are often applied in a wide range of applications where high performance and reliability are required. Machining this kind of material usually comes with great expense in time and money due to its machining characteristics. This is where HIT's Ultrasonic Machining Module comes in handy! We offer a comprehensive solution in machining these difficult-to-cut materials. With the assistance of our Ultrasonic Machining Technology, cutting force is greatly reduced and the coolant can function effectively due to high-speed frequency oscillation. We can assure our clients of fulfilling their needs and even achieving better outcome!
